High-Speed, Reliable Storage Solutions
AIO’s SD Memory Card Controllers are built on TSMC’s 28nm process and support the latest SD 6.1 specification. They support SD Memory Cards ranging from 16GB to 2TB and are available in three product lineups to meet different customer performance requirements.
With support for the DDR225 Host Interface, they deliver higher data transfer speeds than SDR104. LDPC ECC technology enhances NAND Flash error correction and data reliability, while an efficient low-power design optimizes power consumption for mobile and consumer devices, delivering both high performance and reliability.
Features
Supports the Latest
SD 6.1 Specification
Enhanced Data Reliability
with LDPC ECC
Broad NAND Flash
Compatibility
High-Speed Data Transfer
with DDR225
Low-Power, High-Efficiency
Controller Design
Application Performance Class
A2 Support
Specifications
| TS4114 | TS4214 | TS4314 | |
|---|---|---|---|
| Standard | SD 6.0 / 6.1, UHS-I | SD 6.0 / 6.1, UHS-I | SD 6.0 / 6.1, UHS-I |
| Process Node | 28nm CMOS | 28nm CMOS | 28nm CMOS |
| ECC Engine | LDPC | LDPC | LDPC |
| Interface Speed | DDR200 | SDR104 | DDR225 |
| Performance | 180MB/s · 4K IOPS 120MB/s · 2K IOPS |
95MB/s · 4K IOPS 85MB/s · 2K IOPS |
200MB/s · 4K IOPS 120MB/s · 2K IOPS |
| Operating Temperature | -25°C ~ 85°C | -25°C ~ 85°C | -25°C ~ 85°C |
| Operating Voltage | 1.8V / 3.3V | 1.8V / 3.3V | 1.8V / 3.3V |
| NAND Type | 3D TLC | 3D TLC | 3D TLC |
| Maximum Capacity | 2TB | 2TB | 2TB |
Applications
Digital Cameras
Camcorders
Action Cameras
Drones
Dash Cams
Security Cameras
Handheld
Game Consoles
